The EPL soccer feed is back in NS4 from 100.5E.
This week it has 4 matches in the mux, looks to be a reqular at weekends?

Satellite: AsiaSat 5 (100.5E)
Novelsat Modulation: NS4
Frequency: 4178V
Symbol Rate 35294
FEC 19/30
16APSK
Encryption: Tandberg

.


Francescone

Well Known Member
Messages
829
Watching the WTA tennis feed from Riyad at 30.5°E, 11183V SR 7500.
The signal is very weak at my 2.4m dish (North part of Italy), just above the lock threshold, around 8.0-8.2 dB.
Not sure if it is normal, but on every other satellites the signal is good, and also at 30.5°E I get other very strong transponders.
Maybe the beam is not pointing my area? Thanks.


bol@nov

Senior Member
Messages
216
Watching the WTA tennis feed from Riyad at 30.5°E, 11183V SR 7500.
The signal is very weak at my 2.4m dish (North part of Italy), just above the lock threshold, around 8.0-8.2 dB.
Not sure if it is normal, but on every other satellites the signal is good, and also at 30.5°E I get other very strong transponders.
Maybe the beam is not pointing my area? Thanks.
Judging by the footprint there shouldn't even be any signal there, you should be happy to be able to capture this feed, only southern Europe can get it.


Francescone

Well Known Member
Messages
829
Judging by the footprint there shouldn't even be any signal there, you should be happy to be able to capture this feed, only southern Europe can get it.
Well, I'm in Southern Europe (North Itay), not sure what region you mean.
However, after 6pm local time (5pm GMT) the signal was weaker, and I was no more able to lock.


bol@nov

Senior Member
Messages
216

As you can see in picture the beam that transmits this feed does not cover your location, you can capture only at the limit, to get a better signal you need a bigger dish or move to south of Italy.
To conclude, it is normal for you to have low signal.


AhmedCeNa

Donating Member
Messages
1,044

As you can see in picture the beam that transmits this feed does not cover your location, you can capture only at the limit, to get a better signal you need a bigger dish or move to south of Italy.
To conclude, it is normal for you to have low signal.
This is the wrong beam.

The feed is coming from Saudi Arabia, so this is the correct beam (MENA beam)


Attachments

  • IMG_5169.jpeg
    66.4 KB · Views: 18
